PCB sou metal Tag
PCB On Metal Tag la se yon solisyon RFID ki gen gwo -pèfòmans ki fèt pou jesyon ak enspeksyon metal andedan kay la/deyò. Konfòme ak estanda EPC Class1 Gen2/ISO 18000-6C epi li ankapsile nan materyèl FR4, li bay idantifikasyon serye alontèm sou sifas metal yo - depase solisyon konvansyonèl yo nan anviwònman difisil.
Apèsi sou pwodwi a
| Kalite | Dimansyon | Materyèl |
Chip |
Frekans |
Li Range |
Telechaje Materyèl |
| PCB9525 | 95 * 25 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.5m | |
| PCB9525 | 95 * 25 * 3.4mm | FR4 |
M4QT |
902MHz-928MHz oswa 865MHz-868MHz | 0~8m | |
| PCB8020 | 80 * 20 * 3mm | FR4 |
Ukod 8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~8.8m | |
| PCB8020 | 80 * 20 * 3.4mm | FR4 | M4QT | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.8m | |
| PCB7020 | 70 * 20 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~4.6m | |
| PCB6025 | 60 * 25 * 3.4mm | FR4 | M4QT | 902MHz-928MHz oswa 865MHz-868MHz | 0~4.3m | |
| PCB5313 | 53 * 13 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.5m | |
| PCB5010 | 50 * 10 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.5m | |
| PCB4710 | 47 * 10 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~7.5m | |
| PCB3613 | 36 * 13 * 3.4mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.5m | |
| PCB3612 | 36 * 12 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~8.4m | |
| PCB3005 | 30 * 5 * 0.8mm | FR4 | M730 | 902MHz-928MHz oswa 865MHz-868MHz | 0~1.7m | |
| PCB3005 | 30 * 5 * 2mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~4m | |
| PCB2510 | 25 * 10 * 2mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~3.8m | |
| PCB2309 | 23 * 9 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~4.5m | |
| PCB2208 | 22 * 8 * 2mm | FR4 | Ucode 7M | 902MHz-928MHz oswa 865MHz-868MHz | 0~1.5m | |
| PCB1809 | 18 * 9 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~4m | |
| PCB1806 | 18 * 6 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~3m | |
| PCB1504 | 15 * 4 * 2mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~2.2m | |
| PCB1309 | 13 * 9 * 3mm | FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~2m | |
| PCB1307 | 13 * 7 * 3mm | FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~2m | |
| PCB1207 | 12 * 7 * 3mm | FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1.7m | |
| PCB1207 | 12 * 7 * 2mm | FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1.7m | |
| PCB1005 | 10 * 5 * 3mm | FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1.5m | |
| PCB1005 | 10 * 5 * 2mm | FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1.5m | |
| PCB1003 | 10 * 3.6 * 1mm | FR4 | R6P | 902MHz-928MHz oswa 865MHz-868MHz | 0~1.5m | |
| PCB0904 | 9.3 * 4.3 * 1.6mm | FR4 | Ucode7M | 902MHz-928MHz oswa 865MHz-868MHz | 0~1m | |
| PCB2020 |
Dyamèt-20mm Epesè-2mm |
FR4 | Ucode8 | 902MHz-928MHz oswa 865MHz-868MHz | 0~3.7m | |
| PCB1616 |
Dyamèt-16mm Epesè-3mm |
FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~2.1m | |
| PCB1010 |
Dyamèt-10mm Epesè-3mm |
FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1m | |
| PCB0505 |
Dia-5mm Epesè-3mm |
FR4 |
Ucode8 |
902MHz-928MHz oswa 865MHz-868MHz | 0~1m | |
LaPCB sou metal Tagse yon solisyon RFID ki gen gwo -pèfòmans ki fèt pou jesyon ak enspeksyon metal andedan kay la/deyò. Konfòme ak estanda EPC Class1 Gen2/ISO 18000-6C epi li ankapsile nan materyèl FR4, li bay idantifikasyon serye alontèm sou sifas metal yo - depase solisyon konvansyonèl yo nan anviwònman difisil.
Avantaj kle yo
• Ranje lekti siperyè:
Reyalize 9m (lektè fiks) ak 4.5m (pòtal) sou metal - ideyal pou aplikasyon pou depo / odit.
• Konsistans RF:
ChakPCB sou metal Tagse valide atravè Voyantic Tagformance™ (EU-sètifye), ki asire estabilite pakèt-a-pakèt nan echèl.
• Rezilyans anviwònman an:
Konstriksyon FR4 ak evalyasyon IP65 siviv gout, tès chimik siye, ak monte bisiklèt tèmik.
Aplikasyon
• Depo etajè & Suivi machin
01
• IT/idantifikasyon kabinè pouvwa
02
• Veso metal & jesyon byen pwodiksyon
03
• Odit fidbak ak envantè byen fiks
04
Tag sa a sèvi kòm yon mwayen debaz pou enspeksyon ekipman, navigasyon AGV, ak nimerik avantaj.
Enstalasyon
• Vis/rive:
Pou aliye pèmanan
• Adezif dèyè (opsyon 3M™ VHB):
Fè egzèsis-kosyon gratis
• Custom make:
Logo enprime / ekran enprime / engraving lazè
Garanti pèfòmans
✓ Siklis tèmik: -40 degre a +150 degre
✓ Rezistans chimik: Siye alkòl/gazolin-prèv
✓ IP65 ki enpèmeyab + teste gout
✓ 50-ane kenbe done (1-ane garanti)
✓ Sipò pou frekans mondyal: 902-928MHz / 865-868MHz
Pwen esansyèl pwodwi yo
● Lizibilite sifas metal-san konpwomi
● Zewo-deplwaman risk atravè validasyon pakèt
● Versatile aliye: opsyon vis / adezif / te fè bak
● Endistri-pwouve atravè depo, enstalasyon elektrik, ak ekipman biwo
● Idantifyan personnalisable: Sifas mak/QR kòd
